6-24
TECHNICAL DATA ORBAN MODEL 9400
PART # DESCRIPTION COMPONENT IDENTIFIER
C705, C706, C707, C708, C709,
C710, C711, C712, C713, C714,
C715, C716, C718, C719, C720,
C723, C724, C725, C726, C727,
C728, C729, C732, C733, C734,
C739, C740, C741, C742, C743,
C744, C749, C751, C752753, C754,
C755, C756, C757, C758, C759,
C760, C761, C762, C775, C802,
C803, C805, C806, C808, C809
21141.000.01 CAPACITOR, NPO, 1000PF, 1%, 0805 C601, C771, C772, C773, C774
21227.747.01
CAPACITOR RADIAL LEADS 470UF
16V HFS
C777, C778
21230.710.01
CAPACITOR RADIAL LEADS 100UF
50V HFS
C776
21309.622.01
CAPACITOR TANTALUM SMT 0.22uf
20%
C736
21319.610.01 CAPACITOR, 10uf, TANTALUM, SMT C801, 804, 807
22083.033.01
DIODE, VOLTAGE SUPPRESSOR, 33
VLT
CR702
22083.068.01
DIODE, VOLTAGE SUPPRESSOR,
6.8 VLT
CR700
22208.040.01 DIODE-SCHOTTKY-31DQ04-3.3 CR703
24543.000.01 IC CY2305 0DLYBUF 8P IC604
24857.000.01 IC 74HC374 DLATCH SOL20 IC504
24944.000.01 IC, EPM 7064AETC44-10, SMT IC503
24945.000.01 IC 74AHC541 OCTLBUF SOL20 IC501
24946.000.01 IC-8 BIT-DUAL TRANSVR W/3 IC502
24948.000.01 IC 74LVC2244 OCTLBUFSOL20 IC601, 602
24955.000.01 IC, SMT, PLL1700, SSOP/20 IC801, 802
24964.000.01 IC, LM2576T-3.3 FLOW LB03 IC703
24993.000.01 IC, EPM7256AE24995TC100-10 IC603
24994.000.01 IC, 74ACT04, SOIC 14P IC807
27421.002.01
CONNECTOR, HEADER, DOUBLE
ROW, 2P, 2 X 1
J500, J616, (ALL, OTHERS)
27421.010.01
CONNECTOR, HEADER, DOUBLE
ROW, 23", 2 X 5
J603
27451.003.01
HEADER, STR, DOUBLE ROW, PC
MOUNT
J701
27451.007.01
CONNECTOR, DOUBLE ROW, PC
MOUNT, 40 PIN
J504
27630.001.01 JUMPER, PC MNT, TEST POINT TP702, TP703
28083.000.01
OSCILLATOR-XTAL CLOCK-27MHZ 3
VOLT
IC804
29504.150.01 INDUCTOR-2A-PE53113 L700
29512.000.01 CHOKE-SHIELDED-1670-1; 25 L701
27401.000.01
CONNECTOR, JUMPER, RECPT,
BLACK
J615, 1-2
27421.004.01
CONNECTOR, HEADER, DOUBLE
ROW, 4P, 2 X 2
J615
24991.120.01.1 IC, DSPB56362AG120
IC101, IC102, IC103, IC104, IC105,
IC106, IC107, IC108
