OPTIMOD-AM DIGITAL TECHNICAL DATA
6-23
Input/Output (I/O) Board: Daughter Board
PART # DESCRIPTION COMPONENT IDENTIFIER
21139.000.01
(0805)
CAPACITOR, CERAMIC, 50V, 0.1UF,
SMT
C2, C5, C6, C7, C8, C9, C10, C11,
C12
21318.510.01
(1206)
CAPACITOR, P, 35V, 10%, 1UF C4
21319.610.01
CAPACITOR, P, TANTALUM, 25V,
10UF, SMT
C3
20131.499.01
RESISTOR, METAL FILM, 1/8W, 1%,
49.9K, SMT
R3, R4, R5, R6
24634.000.01 IC, OCTAL, 74HC241A, SMT IC4
20129.110.01
RESISTOR, METAL FILM, 1/8W, 1%,
110OHM, SMT
R1, R2
21138.247.01
CAPACITOR, CERAMIC, 50V,
4700PF, NPO, SMT
C1
24753.000.01
IC, SAMPLE RATE CONVERTER, 192
KHZ, AD1895AYRS, RS-28, SMT
IC5, IC6
42007.040
CABLE, FLAT, SUBASSEMBLY, 26P,
4"
JP1
24672.000.011
IC, DIGITAL AUDIO INTERFACE
TRANSMITTER, SMT
IC2, IC3
29506.001.01 FERRITE BEAD ON WIRE L1, L2, L3, L4
24335.000.01
IC, LOW NOISE REGULATOR,
100mA, 3.3V, SMT
IC1
29015.000.01 XFMR, SC937-02, SMT T1, T2
27053.003.01 CONNECTOR, RT, PC, MALE, XLR J1, J2
DSP Board
PART # DESCRIPTION COMPONENT IDENTIFIER
16021.000.01
HEATSINK-VERTICAL MOUNT,
BLACK ANODIZED
HS703, USE, COMPND
20128.075.01 RESISTOR, 75OHM, 1%, 0805
R505, R506, R508, R604, R605,
R606, R607, R608, R609, R610,
R611, R612, R613, R806, R807,
R808, R809, R810, R811
20131.100.01 RESISTOR, 10K, 0805
R301, R302, R303, R304, R305,
R306, R307, R308, R507, R510,
R801, R802, R803, R804, R805
20132.100.01 RESISTOR, 100K, 0805
R101, R102, R103, R104, R502,
R503, R504, R509, R601, R602,
R603
20221.101.01
RESISTOR, NET, SIP, 2%, 100K,
10PIN
RN501
21137.282.01
CAPACITOR, 8200PF, +-15%, 1206,
50V
C101, C103, C105, C107, C109,
C111, C113, C115
21137.447.01 CAPACITOR .47UF 25V 10% 1206
C102, C104, C106, C108, C110,
C112, C114, C116
21139.000.01 CAPACITOR, X7R, 0.1UF, 10%, 0805 C600, C701, C702, C703, C704,
