ST 6100 - HARDWARE GUIDE
Parameter Value
Nonvolatile Onboard Flash Storage 8 MB
Write-Erase Cycles (per operating life) 100 000
3.12 RAM
Parameter Value
RAM (volatile memory) 4 MB
3.13 Environmental
Parameter Description
Humidity The terminal meets all its specifications during exposure to 90% relative humidity at +85°C, per the
test methodology of SAE J1455, section 4.2.3.
Vibration The terminal meets all its specifications during exposure to random vehicular vibration levels per
SAE J1455, section 4.9.4.2 and MIL-STD-810G, section 514.6, fig 514.6C-1.
Mechanical Shock The terminal meets all its specifications after exposure to positive and negative saw tooth shock
pulses with peaks of 20G and durations of 11 ms as specified in MIL-STD-810G, section 516.6,
Procedure I, section 2.3.2c, 3/axis/(positive and negative direction).
Altitude The terminal meets all of its specifications after a nonoperating 12.2 km altitude test as detailed in
SAE J1455, section 4.9.3, except with an ambient temperature of -40°C.
Thermal Shock The terminal meets all of its specifications after a thermal shock test as detailed in SAE J1455,
section 4.1.3.2
Salt Spray Atmosphere The terminal meets all of its specifications after a salt spray test as detailed in SAE J1455, section
4.3.3.1.
Immersion The terminal meets all of its specifications after a 6 hour alternating hot/cold salt water immersion
test as detailed in SAE J1455, section 4.3.3.2.
The terminal meets all of its specifications after a 30 minute, 1 m depth fresh water immersion test
as detailed in IEC 60529, section 14.2.7.
These immersions were performed without a cable mating with the circular connector.
T406, VERSION 01
29
© ORBCOMM PROPRIETARY
