8 9
DripMaster
®
FOR POTTED PLANTS
4
Attach Multi-Stream Drippers to
each 1/4" Distribution/Supply Line
and insert stake next to each plant.
5
Remove the 1/2" End Cap and
turn on water to flush system; replace
cap.
6
Adjust water flow by twisting the
top of the Multi-Stream Dripper.
FOR HANGING PLANTS
4
Attach Adjustable Flow Mist
Sprayers to each 1/4"
Distribution/Supply Line and aim
sprayer into the hanging basket.
5
Continue running lines to each
hanging basket until the system is
completed.
6
Remove the 1/2" End Cap and
turn on water to flush system; replace
cap.
7
Rotate the flow control knob on
the Mist Sprayer to adjust flow rate.
IMPORTANT: The maximum
recommended number of Multi-Stream
Drippers and Mist Sprayers per 1/2"
supply line is 15.
Supplies needed
- 1/2" Tube Straps (part # 65716 or 69716)
- 1/4" Tube Straps (part # 65715 or 69715)
- 1/4" Distribution/Supply Tube (part # 67300, 67301 or 67303)
- 1/4" Barbed Couplers (part # 67402 or 69402)
- Stake with Multi-Stream Dripper (part # 67105 or 69105)
- Adjustable Flow Mist Sprayer (part # 67190 or 69190)
- Punch Tool (part # 67756 or 69756)
SECTION
4
POTTED / HANGING PLANTS
Note: Steps 1–3 apply to both potted & hanging plants
1
Distribution/Supply Line—Place the 1/2" Distribution/Supply Line close
to your Potted or Hanging Plants. Use 1/2" Tube Straps to secure the Tube and
install a 1/2" End Cap.
2
Hole Punch—Punch holes in
the 1/2" Distribution/Supply Line
for each container or hanging basket.
Next, insert 1/4" Barbed Couplers
into each hole.
3
Connect 1/4" Distribution/Supply
Line to each exposed Barbed Coupler
and run the Distribution/Supply Line
to each container/basket. Use 1/4"
Tube Straps to hold in place.
IMPORTANT: A single 1/4"
Distribution/Supply Line should not
exceed 30'.
