INTRODUCTION
Refer to this page when following assembly instructions which call out a specific name
and part number.
These parts are included to complete the assembly of the OREGON
®
Bench-Mounted Mini Grinder.
1. Depth adjustment knob
2. Grinding wheel, 3/16"
3. Shield guard
4. Large washer
5. Flange nut
6. Shield guard screw
7. Knob
8. Vise assembly
9. Dressing brick
10. Template
11. Handle bolt
12. Operating handle
Note: For Replacement parts of bench-mounted or bar-mounted mini grinders, see the exploded
view descriptions on pages 18 through 20.
PARTS INCLUDED FOR ASSEMBLY
