ORGAPACK CR 26 A
01.08/WE
1 TECHNICAL DATA
TABLE OF CONTENTS
Weight 9.3 kg (20.4 lbs)
Dimensions Length 470 mm (18.5“)
Width 170 mm (6.7“)
Height 300 mm (11.8“)
Tension force Up to approx. 8400 N
Tension speed 90 mm/s (3.54“/s)
Air pressure Maximum 6 bar static
Air consumption
– Tensioning 6.4 Nl/s
– Sealing 14 Nl
Air connection G
1
/
4
“ (
1
/
4
“ NPT)
Sealing Sealjoint with double notch
Emission sound pressure
levels, measurement
type A (EN ISO 11202) L
pA
76 dB (A)
Vibrations at handle
(EN ISO 8662-1) a
h,w
< 2,5 ms
-2
STEEL STRAP
Strap width 25, 32 mm
(1“, 1
1
/
4
“)
Normal quality:
Strap thickness 0.80–1.00 mm (.031“–.040“)
Tensile strength Up to approx. 850 N/mm
2
(120‘000 lbs/in
2
)
High strength quality:
Strap thickness Up to 0.80 mm (–.031“)
Tensile strength Up to approx. 1100 N/mm
2
(157‘000 lbs/in
2
)
SEALS
Strap width 25 mm CSP 717
Strap width 32 mm CSP 817
Page
1 Technical data 17
2 General information 18
2.1 Information on environmental protection 18
3 Safety instructions 19
4 Description 20
4.1 Design 20
4.2 Function 20
5 Initial operation 21
5.1 Suspending the tool 21
5.2 Compressed-air connection 21
6 Operating instructions 22
6.1 Operating the tool 22
7 Preventive and corrective maintenance 24
7.1 Adjusting tensioning force/tensioning speed 24
7.2 Setting clearance between tension wheel and
tension plug 24
7.3 Replacing tension wheel 24
7.4 Replacing jaws and notcher 25
7.5 Cleaning the tool 25
8 Parts list 26
Explosion drawing 28
9 Parts list compressed air motor 29
Explosion drawing 30
We take sole responsibility for declaring that the
tool CR 26 A, to which this declaration refers, is
in full compliance with the current requirements of
the guidelines laid down by the council on 22th
June 1998 (98/37/ECC), “Machine Guidelines“.
According to norm:
EN ISO 12100-1, EN ISO 12100-2, EN 349,
EN 983, EN 1050 prEN 792-2
DECLARATION OF AGREEMENT
CH-8953 Dietikon, April 2001
Manager Manager
Sales & Marketing: Engineering:
R. Kieffer M. Binder
