26
01.08/WE
ORGAPACK CR 26 A
1 1831.011.003 Cylinder complete 1
2
3
4
5
6 1831.011.004 Retaining ring 1
7 1820.020.281 Washer 1
8 1831.011.005 Housing complete, incl. pos. 9-11 1
9 1935.510.100 Radial slide bearing, ø 10/12 x 10 1
10 1935.000.200 Internal ring, ø 9/12 x 12 1
11 1935.510.150 Radial slide bearing, ø 10/12 x 15 1
12
13 1831.032.003 Gear housing incl. pos. 14 1
14 1821.020.031 Bushing 1
15
16
17 1832.039.002 Cover 1
18 1174.400.051 Flange 1
19 1174.400.067 Silencer 1
20 1831.032.001 Bearing plate 1
21
22
23 1821.101.002 Piston 1
24 1831.011.014 Base plate, 0,8 mm 25 mm 1
24 1831.011.007 Base plate 25 mm 1
24 1831.011.006 Base plate “E“, 0,8 mm 32 mm 1
24 1831.011.008 Base plate “E“ 32 mm 1
25
26 1831.021.012 Plate front 25 mm 1
26 1831.021.013 Plate front 32 mm 1
27 1831.021.002 Plate rear 25 mm 1
27 1831.021.004 Plate rear 32 mm 1
28 1174.400.061 Slider 25 mm 1
28 1831.021.005 Slider 32 mm 1
* 29 1821.200.005 Jaw 25 mm 4
* 29 1821.200.004 Jaw 32 mm 4
* 30 1821.200.002 Notcher 25 mm 1
* 30 1821.200.003 Notcher 32 mm 1
31 1174.400.065 Link 25 mm 2
31 1821.205.003 Link 32 mm 2
32
33 1934.450.060 Counter washer,
ø 6/13,4 x 2 4
34 1820.030.444 Bolt 25 mm 1
34 1821.033.004 Bolt 32 mm 2
35 1821.033.008 Bolt 4
* 36 1820.030.439 Bolt 2
37 1820.020.278 Bushing 2
38 1916.306.062 Lock nut, M 6 4
39
* 40 1821.208.002 Cutter, incl. pos. 41 25 mm 1
* 40 1821.208.011 Cutter “A“, incl. pos. 41 25 mm 1
When ordering please indicate part number and quantity Explosion drawing see page 28
* Recommended spare parts
Pos. Part no Part name Quantity
8 PARTS LIST 1831.002.001/14
Pos. Part no Part name Quantity
* 40 1821.208.009 Cutter “E“, incl. pos. 41 32 mm 1
41 1921.602.081 Spiral pin, ø 2,5 x 8 1
42
43 1927.614.020 O-Ring, ø 140 x 2 1
* 44 1927.601.410 O-Ring, ø 14 x 1,5 1
45 1928.011.500 K-Ring, ø 150 1
46 1820.020.277 Washer 2
47
48 1916.308.082 Lock nut, M 8 1
49
50
51 1820.100.032 Bushing 1
52 1820.010.047 Compression spring 1
53 1925.010.802 Ball 1
54 1820.100.041 Valve stem short 1
* 55 1927.601.600 O-Ring, ø 16 x 1 6
56 1820.100.031 Bushing 1
* 57 1927.600.420 O-Ring, ø 4 x 2 1
58
59
60
61 1821.010.001 Compression spring 1
62 1820.100.039 Ring 1
63 1820.100.042 Valve stem long 1
64
* 65 1927.600.820 O-Ring, ø 8 x 2 5
66 1820.100.038 Sleeve 2
67 1820.100.037 Sleeve 1
68
* 69 1927.600.600 O-Ring, ø 6 x 1 3
70 1927.601.710 O-Ring, ø 17 x 1,5 1
71
72 1821.034.004 Shaft 1
73 1821.020.016 Bushing 1
* 74 1820.040.098 Tension wheel 1
75 1917.401.145 Space washer, ø 14/26 x 0,5 2
76 1933.914.120 Needle bearing, ø 14/20 x 12 2
77 1921.306.220 Straight pin, ø 6 x 22 1
78
79 1821.070.001 O-Ring, ø 3,5 x 1,5 1
80
81
82 1933.722.162 Needle bushing, ø 22/28 x 16 1
83 1934.310.350 Thrust bearing, ø 35 1
84
85 1821.063.002 ZTA-Wheel 1
86 1821.063.001 ZTA-Pinion 1
87 1831.033.001 Shaft 1
88 1926.502.200 Free wheel, ø 20/26 x 26 1
89 1934.330.151 Needle bearing, ø 15/28 x 6 1
90
