Orgapack CR 26 A - 9 Parts List Compressed Air Motor

To Next Page

To Previous Page

01.08/WE

ORGAPACK CR 26 A

1 1894.432.012 End plate 1

2 1894.432.011 Gear housing ( Rear side) 1

3 1894.432.026 Silencer 1

4 1894.432.027 Mesh screen 1

5 1894.432.005 Ball bearing 1

6 1894.432.004 Bearing plate rear 1

7 1894.432.006 Pin 1

8 1894.432.003 Cylinder 1

9 1894.422.001 Rotor 1

10 1894.422.002 Blade 5

11 1894.432.002 Key 1

12 1894.432.009 Bearing plate front 1

13 1894.432.001 Ball bearing 1

14 1894.432.013 Washer 1

15 1894.432.021 Ball bearing 4

16 1894.332.015 Shaft 2

17 1894.332.016 Needle cage 2

18 1894.422.003 Planetary wheel 2

19 1894.422.004 Planetary shaft 1

20 1894.432.025 Threaded bushing 1

21 1894.432.024 Saucer spring 2

22 1894.432.017 Shaft 2

23 1894.332.024 Bearing needle 32

24 1894.432.016 Planetary wheel 2

25 1894.432.018 Planetary shaft 1

26 1894.432.023 Gear housing ( Front side) 1

27 1894.332.027 Gasket 1

28 1894.432.022 Front part 1

When ordering please indicate part number and quantity Explosion drawing see page 30

9 PARTS LIST COMPRESSED AIR MOTOR 1894.422.000/1

Pos. Part no Part name Quantity
