Orgapack CR 26 A - 6 Operating Instructions; Operating the Tool

22
01.08/WE
ORGAPACK CR 26 A
6.1 OPERATING THE TOOL
– Draw the strap from the dispenser, slide the strap
through the seal (4/1) and wind strap around the
package.
– Push the strap start a second time through the seal.
– Bend the strap start (4/2) below the seal 3–4 cm
(1–2“).
– Pull the strap tightly by hand and take a portion of
the strap leading to the dispenser with the left hand
approx. 20 cm (8“) away from the seal.
– Hold the handle (5/1) of the tool in the right hand
and raise the motor up to the stop.
– Insert the strap below the tension wheel completely
into strap guide. At the same time push the tool
forward against the seal.
– Release the motor.
6 OPERATING INSTUCTIONS
Fig. 4
Fig. 5
Fig. 6
Tensioning
– Press the green button (6/1) completely down with
the thumb of the right hand, until the required strap
tension is reached.
The maximum tensioning force can be
infi nitely adjusted (see chapter 7.1).
1
2
1
1
