23
ORGAPACK CR 26 A
01.08/WE
Sealing
– Press the yellow button (7/1) with the right thumb
until the seal is notched and the strap is cut off.
– Raise the motor up to the handle (8/1) and swivel
the tool away from the strapping to the right at the
rear.
Check of seal
To obtain the maximum seal effi ciency, the notches
have to be cut properly into the seal. If these notches
are not correctly cut, replace jaws and notcher (see
chapter 7.4).
Fig. 7
Fig. 8
