Orgapack CR 26 A - Page 27

27
ORGAPACK CR 26 A
01.08/WE
91
92
93
94 1894.422.000 Air motor, LZB 33 A 005-63 1
95 1895.312.003 Woodruff key 1
96
97
98
99
100
101 1821.039.021 Bolt 2
102 1820.020.279 Bushing 2
103
104
105 1820.030.442 Locking screw 1
106 1925.210.042 Saucer spring (14 pieces) 1
107 1820.030.441 Bolt 1
108 1925.010.702 Ball, ø 7 1
109 1820.030.443 Set screw 1
110 1174.400.069 Roll 1
111 1174.400.068 Suspension bow 1
112
113
114 1174.400.076 Lever green 1
115 1174.400.077 Lever yellow 1
116
117 1174.400.078 Shaft 1
118 1920.103.062 Lock washer, ø 3,2 2
119
120
121
122
123
124
125 1174.400.079 Pawl 1
126
127
128 1911.305.162 Cylinder screw, M 5 x 16 3
129 1911.005.258 Cylinder screw, M 5 x 25 6
130 1911.005.168 Cylinder screw, M 5 x 16 4
131 1911.005.128 Cylinder screw, M 5 x 12 4
132 1919.605.062 Lock nut, M 5 12
133 1917.803.056 Washer, M 5 2
134
135
136
137 1820.010.144 Compression spring 1
138 1933.910.120 Needle bearing, ø 10/14 x 12 1
139
140 1941.112.720 L-Connection, G 1/4” 2
141 1941.111.040 Hose connection, G 1/4” 2
142 1940.070.723 One-way restrictor, G 1/4” 1
143
144
145 1941.210.720 Gasket, G 1/4” 7
146 1940.331.188 Hose clamp, ø 18 2
147 1941.202.722 Hollow screw, G 1/4” 1
148 1173.400.044 Air hose 1
149
150
151
152 1910.505.062 Set screw, M 5 x 6 1
* 153 1820.040.109 Tension plug 1
154 1820.010.230 Torque spring 1
155 1174.400.074 Strap guide lever 1
156 1820.020.280 Bushing 2
157 1820.010.231 Torque spring 1
158
159
160
161 1940.311.721 Air plug, G 1/4” 1
162 1911.272.127 Locking screw, G 1/4” 1
163
164 1820.090.068 Oil label 1
165
166 1820.090.198 Name tag 1
167 1820.090.172 Label “Made in Switzerland“ 1
Variation USA/CAN
161 1820.100.019 Air connector, 1/4” NPT 1
163 1820.100.017 Transition connection,
G 1/4”–1/4” NPT 1
Pos. Part no Part name Quantity
Pos. Part no Part name Quantity
