Regulations and standards
220
8 Reference materials
3 Regulations and standards
3-1 UL Standards (AC power input driver only)
Check the "APPENDIX UL Standards for AZ Series AC power input type" for recognition information about UL
Standards.
3-2 EU Directives

CE Marking (AC power input driver)
This product is axed the CE Marking under the Low Voltage Directive and EMC Directive.
z
Low Voltage Directive
Applicable standards EN 61800-5-1
Installation conditions
(EN Standards)
To be incorporated in equipment.
Overvoltage category: II
Pollution degree: 2
Degree of protection: IP10
Protection against electric shock: Class I equipment
•
This product cannot be used in IT power distribution systems.
•
Install the product inside an enclosure in order to avoid contact with hands.
•
Be sure to maintain a protective ground in case hands should make contact with the product. When installing the
motor and driver, securely connect their Protective Earth Terminals.
•
To protect against electric shock using an earth leakage breaker (RCD), connect a type B earth leakage breaker to
the power supply side of the driver.
•
Use a molded case circuit breaker (MCCB) that conforms to EN standards or IEC Standards.
•
Isolate the motor cable, the power supply cable and other drive cables from the signal cables by means of double
insulation.
•
The temperature of the driver's heat sink may exceed 90 °C (194 °F) depending on the driving condition. Observe
the followings.
· Do not touch the driver while operating.
· Do not use the driver near combustibles.
· Be sure to perform a test operation and check the driver temperature.
z
EMC Directive
This product is conducted EMC testing under the conditions specied in "Example of installation and wiring" on
p.36. The conformance of your mechanical equipment with the EMC Directive will vary depending on such factors
as the conguration, wiring, and layout for other control system devices and electrical parts used with this product. It
therefore must be veried through conducting EMC measures in a state where all parts including this product have
been installed in the equipment.
Applicable Standards
EMI
EN 55011 Group1 Class A
EN 61000-6-4
EN 61800-3
EMS
EN 61000-6-2
EN 61800-3
This equipment is not intended for use in residential environments nor for use on a low-
voltage public network supplied in residential premises, and it may not provide
adequate protection to radio reception interference in such environments.
