Function and logic of
the digital input:
0 = No function
1,2 = Door opening
3 = Door opening with
door blocking
4 = External alarm
5 = External alarm with
exit’s deactivation.
6 = Selection in
between Normal or
Economic mode.
7 = Start / Stop (Stand-
by)
8 = DO NOT USE
-8 / -7 / -6 / -5 /
-4 / -3 / -2 / -1 /
0 / 1 / 2 / 3 / 4 /
5 / 6 / 7 / 8
0
12
i.ti
Digital input delay.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
13
i.Et
Delay time of
economic mode
activation when the
door is closed
oF = disabled function.
oF/ 0.01 ÷ 9.59
(hrs.min.) ÷
99.5
(hrs.min.x10)
oF
14
i.tt
Maximum time of
operation in economic
mode.
oF = disabled function
oF/ 0.01 ÷ 9.59
(hrs.min. ) ÷
99.5
(hrs.min.x10)
oF
15
i.dS
Variable often shown
in the display:
P1 = Measuring probe
Pr1.
P2 = Measuring probe
Pr2
Ec = Pr1 Measure in
normal mode and Eco
message in Eco mode
SP= Active Set Point
oF = Turned off display
P1 / P2 / P3 /
Ec / SP / oF
P1
“r” Temperature regulation parameters
Par.
Description
Range
Def.
Note
16
r.d
Regulation differential
(hysteresis)
0 ÷ 30
°C/°F
2.0
17
r.Ed
Regulation differential
(hysteresis) in Eco
mode
0.0 ÷ 30.0
°C/°F
2.0
18
r.t1
Output activation time
in case the Pr1 probe
breaks.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
19
r.t2
Output stopping time
because of the
breaking of the probe.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
20
r.HC
Regulation mode:
H = Heat
C = Cool
Nr, HC, C3 = DO NOT
USE
H / C / nr / HC /
C3
C
“d” Relative parameters to the defrosting
Par.
Description
Range
Def.
Note
21
d.tE
Defrosting finishing
temperature
- 99.9 ÷ 999
°C/°F
10.0
22
d.tS
Temperature from
which the beginning of
the defrosting is
allowed. If Pr2 is
higher tan d.tS it won’t
start the defrosting.
- 99.9 ÷ 999
°C/°F
2.0
23
d.tF
Temperature that
forces the beginning of
the defrosting.
- 99.9 ÷ 999
°C/°F
-99.9
24
d.St
Delay in the beginning
of a defrosting
because of Pr2
evaporator probe
oF/ 0.01 ÷ 9.59
(min.sec) ÷
99.5
(min.sec.x10)
1.00
25
d.dL
Display locking in the
defrosting:
oF = not active
on = active with last
measurement.
Lb = active with
message (“dEF” in
defrosting and “PdF” in
post-defrosting)
oF - on – Lb
oF
26
d.cd
Defrosting starts due
to continual operation
of the compressor
oF/ 0.01 ÷ 9.59
(hrs.min. ) ÷
99.5
(hrs.min.x10)
oF
27
d.dE
Maximum duration of
the defrosting.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
28
d.PE
Probe selection of the
finish of the defrosting:
- oF = finishes by time
alone.
- EP = by Pr2 probe
temperature = EP.
- P1 = by Pr1 probe
temperature = room.
oF – EP – P1
EP
29
d.di
Defrosting intervals
oF ÷ 0.01 ÷
9.59 (hrs.min)
÷ 99.5
(hrs.min)
oF
30
d.Sd
Defrosting delay when
starting. (oF = it allows
defrosting when it
starts)
oF ÷ 0.01 ÷
9.59 (hrs.min)
÷ 99.5
(hrs.min)
oF
31
d.Ei
Defrosting intervals if
there is a probe error.
oF ÷ 0.01 ÷
9.59 (hrs.min)
÷ 99.5
(hrs.min)
6.00
32
d.EE
Duration of the
defrosting if there is a
probe error
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
10.0
“P” Compressor Protection parameters
Par.
Description
Range
Def.
Note
33
P.P1
Output delay when
starting
oF÷ 0.01 ÷
9.59 (min.sec )
÷ 99.5
(min.sec.x10)
oF
34
P.P2
Delay after stopping or
minimum time of
stoppage.
oF ÷ 0.01 ÷
99.5
oF
35
P.P3
Minimum time after two
output connections.
oF ÷ 0.01 ÷
99.5
oF
36
P.od
Delay of the
compressor’s start
when it gives voltage
to the controller.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
