EXPLORE ASSEMBLY
SEAT REMOVAL
EXPLORE ASSEMBLY
SEAT REMOVAL
Remove the x2
M6x16mm flanged
bolts that secure the
padded seat.
33
4
Remove seat unit by
first lifting the seat
and then pulling
backwards.
34
Undo the x2
M6x16mm flanged
bolts that hold the
moulding that sits
below the seat.
35
4
Remove the plastic
part by first lifting
from the front to
disengage the clips
and then move
upwards.
36
