oset TXP 24 - Bar Pad; Seat Removal

EXPLORE ASSEMBLY
SEAT REMOVAL
ASSEMBLY
BAR PAD
30 31
!
WARNING
To install the bar
pad - push the pad
down until it wraps
the handlebars and
sits on the stem.
29
Affix the included
cable ties, ensuring
they sit in the
grooves on the sides
of the bar pad.
Trim the excess ties.
30
In order to fit the
rear mudguard -
first remove the x2
M6x16mm flanged
upper rear
splashguard bolts.
31
4
The splashguard can
now be removed to
show the padded
seat base bolts.
32
