SUSPENSION SETUPSUSPENSION SETUP
During initial
setup, the fork
compression
damping adjuster
must be wound
completely off
(where fitted).
Rotate the dial in the
direction that
indicates less
compression.
55
Remove both of the
air valve caps from
the top of the fork
leg and side of the
rear shock body.
(Replace these caps
once the suspension
setup is complete).
56
Inflate the fork/
shock to the
appropriate
pressure for the
rider’s weight, as
outlined in the initial
setup pressure
table overleaf.
57
6.3
With the suspension
set to the
suggested
pressures, stand on
the bike in a neutral
riding position.
With your weight
applied, slide the O-
rings on both the
fork and shock
stanchions down to
the seal, before
carefully
dismounting the
bike.
58
