BATTERY
REMOVAL & REFITTING
BATTERY
CHARGING
NOTICE
To charge the
battery - remove the
kill switch from the
bike and turn the
battery off.
Remove the main
battery connector by
turning the collar of the
connector anti-
clockwise.
79
Carefully align the
charger connector and
push into the charge/
discharge port.
A click lets you know it
has been connected
successfully.
Plug the charger into
the mains supply and
turn on.
80
Release the battery
strap from the
handle of the
battery.
82
Lift the battery and
remove from the
bike.
Take care when
lifting as the battery
is heavy.
83
To remove the
battery - remove the
main battery
connector by turning
the collar of the
connector anti-
clockwise.
DO NOT ROTATE OR
PULL THE
CONNECTOR.
81
