2. Installation
2.1 Unpacking and Inspection
After receiving the MX-5050, examine the case for any signs of damage. Then unpack
and inspect the equipment. Take care when unpacking the equipment and removing
packing materials to prevent damaging the critical components such as the capstan,
head assembly, and tension arms. If there is any evidence of damage due to rough
handling during transportation, a claim should be filed with the transportation company. We
recommend retaining the packing material at least until proper operation of the machine has
been established.
Verify that all items, as listed in the following table, have been received. Do not connect or
operate the MX-5050 until this inspection has been completed.
When sending the machine back to the local Otari dealer or to Otari, follow the packing
directions printed on the carton.
MX-5050 BIII, MKIV-2 Standard Accessories
Part Name Part No. Quantity
Reel Clamper
KW0HV---
2
Power Cable
PZ9D003-
1
Manual
OS3-298-
1
Lubrication Oil
PZ9E003-
1
Fuse 1 A
FH7F010-
1
(Fuse 1 A, 200–240 V only
FH9-032-
1)
Fuse 2 A
FH9-030-
1
Fuse 2 A
FH7F020-
1
Fuse 3 A
FH7F030-
1
Fuse 4 A
FH7F040-
1
Fuse 5 A
FH7F050-
1
MX-5050mkIV-2/BIII-2 Operation and Maintenance Manual
4 1999-02
