CHAPTER THREE
Getting started
34
Getting started
3.2 Removing the Otoport from the ABR
Module
If you need to remove the Otoport from the ABR Module at a later time,
carefully follow these steps:
3.2.1 Open the clips on each side.
3.2.2 Slide the top half of the ABR sleeve up and and tilt it back.
3.2.3 Move the Otoport up to disconnect it from the port at the bottom of the
sleeve and remove it from the Module. Do NOT tilt the Otoport forward.
while lifting it up.
3.3 Otoport OAE+ABR with non-removable
module
If you have purchased an Otoport OAE+ABR with a permanently tted
sleeve, sometimes referred to as ‘locked’, it is not possible to remove the
Otoport from the module.
The clips on the side of the locked module are at.
The clips on the unlocked module are shaped for ease of opening.
Non-release clips on ‘locked’ module
Quick-release clips on ‘unlocked’ module
