CHAPTER THREE
Getting started
36
Getting started
3.4.2 Connecting the electrodes
The Otoport OAE+ABR is supplied with an electrode cable loom featuring
snap stud connectors for electrode attachment. Alternatively, any wired
electrodes that are terminated with 1.5mm ‘Touchproof’ DIN 42-802
connectors may be used.
Carefully align the electrode connector plug with the appropriate electrode
socket (observe colour coding) and then push in rmly.
To disconnect the electrode connector, grasp the plug body and pull
straight out from the socket.
Important note:
Do not unplug by pulling on the electrode cable as this may
damage the cable/plug assembly.
