Audiometry icons
Tone audiometry
Speech audiometry
Menu item Icon Description
Combined Audiogram
Click to toggle between viewing both ears in a single audiogram (com-
bined audiogram) or both a left and a right audiogram on your screen.
Combined View
• Click to view both ears in a single audiogram.
Split View
• Click to view separate audiograms for each ear.
Masking Assistant
Enable or disable the Masking Assistant.
The Masking Assistant causes an unmasked threshold to flash
repeatedly if masking is recommended.
Standard
Frequencies/All Fre-
quencies/ High Fre-
quencies
The graph shows up to 20,000 Hz. MADSEN Astera² presents stimulus
up to 12,500 Hz.
• Click to choose between viewing:
StandardFrequencies
Displays the audiogram from 125 to 8000 Hz.
All Frequencies
Displays the audiogram from 125 to 20,000 Hz.
High Frequencies
Displays the audiogram from 8000 to 20,000 Hz.
New Audiogram
Select new audiogram. You will be prompted to save or cancel current
data.
Otometrics - MADSEN Astera²
13
9 Toolbar icons in the Audiometry Module
