Discovery
Max. load when using a parallel seating shell interface
(frame width 360mm)
75kg (165lbs)
Max. load when using a parallel seating shell interface
(frame width 400–450mm)
100kg (220lbs)
Discovery Minimum Maximum
Gross weight (without user) 18kg 34kg
1)
Weight of the heaviest removable component:
• Leg support with continuous foot support for seat
ing shell interface
--- 2.5kg (5.5lbs)
• Arm support, height-adjustable
--- 1.9kg (4.2lbs)
• 24" drive wheel
--- 1.8kg (4lbs)
• Leg support, elevating with ratchet joint
--- 1.8kg (4lbs)
• 22" drive wheel
--- 1.7kg (3.7lbs)
• Leg support, segmented, aluminium
--- 1.6kg (3.5lbs)
Overall length (with 12" drive wheels)
2)
750mm (29.5") 800mm (31.5")
Overall length (with 22" drive wheels)
2)
875mm (34.4") 925mm (35.4")
Overall length (with 24" drive wheels)
2)
900mm (36.4") 950mm (37.4")
Overall width (with 12" drive wheels) 550mm (21.7") 690mm (27.2")
Overall width (with 22"/24" drive wheels) 570mm (22.4") 710mm (28")
Length (folded) no deviation from overall length
Width (folded) no deviation from overall width
Height (folded) 530mm (20.9") 740mm (29.1")
Static stability, uphill
3), 4)
--- 10° (17.6%)
Static stability, downhill
4)
--- 12° (21.3%)
Static stability, sideways
4)
--- 10° (17.6%)
Dynamic stability, uphill
4)
--- 6° (10.5%)
Seat bottom angle (seat tilt) 0° 35°
Effective seat depth 405mm (16") 480mm (19")
Effective seat width 360mm (14.5") 500mm (20")
Front seat height
5)
450mm (17.7") 550mm (21.6")
Back support angle 0° 30°
Back support height 440mm (17.3")
(standard)
620mm (24.4")
(extended)
Distance foot support to seat bottom
6)
130mm (5.1") 350mm (13.8")
Angle between leg support and seat bottom
7)
5° 85°
Distance arm support to seat bottom
6)
60mm (2.4") 390mm (15.4")
Distance front edge of arm support to front edge of
wheelchair
140mm (5.5") 145mm (5.7")
Handrim diameter 490mm (19.3") 540mm (21.3")
Horizontal axle position 150mm (5.9") 300mm (11.8")
Minimum turning radius
8)
740mm (29.2") ---
Adjustment range, push handles/push bars
9)
--- ~ 200 mm (8")
Load capacity of storage bag (optional) --- 5kg (11lbs)
1)
Encompasses the maximum installation of accessories, including tray
2)
Without seating unit and activated anti-tipper; varies depending on installed leg support
3)
2x anti-tipper mandatory with Care Chair version
4)
Depending on seat positioning
5)
At full tilt, with 12" drive wheels: 470mm (18.5")
6)
Discovery with seat plate without seat cushion; other seating systems vary
7)
Depending on the type of leg support, maximum value with elevating leg support
8)
Discovery Standard with 360mm frame width and 12" drive wheels; in accordance with ISO7176-5
