Otto Bock Ventus - Technical Data Overview; General Technical Information; Additional Technical Information

General information
Ventus
Maximum load capacity [kg] 100 (for seat width 280–440)
140 (for seat width 460–500)
Weight [kg]
1)
(for seat width 440 mm; 4" full rubber caster wheels, 24"
hollow rim)
approx. 12.5
Transport weights [kg]
1)
;
(for seat width: 440 mm; 4" full rubber caster wheels)
Frame: 7.5–8.8
24" rear wheel: 3.7
Seat width [mm]
2)
280–440 (max. load capacity 100 kg)
460–500 (max. load capacity 140 kg)
Seat depth [mm]
2)
300 – 500
Max. overall height [mm]
(for rear seat height: 500 mm; back height 500 mm; push
handle)
1050
Min. tyre pressure [bar]
3)
7
Steering range approx. [mm]
4)
(for seat width 440 mm; seat depth 500 mm)
1150 (without wheelbase extension)
1250 (with wheelbase extension)
Max. permissible inclination [°]
5)
Max. permissible inclination [%]
5)
10
17
1)
The specified weights vary according to the selected options and model.
2)
In accordance with ISO 7176-5, 8.12
3)
Varies according to tyre option; see the print on the tyre wall
4)
Turning range/turning circle in accordance with ISO 7176-5, 8.11/8.12
5)
The anti-tipper is mandatory for an inclination of more than 10°.
Additional information
Ventus Minimum Maximum
Mass of the heaviest component [kg] --- 8.8
Overall length with footrests [mm]
1)
755 970
Overall width [mm] 450 850
Seat height difference front/rear [mm] 0 90
Effective seat depth [mm] 300 500
Effective seat width [mm] 280 500
Front seat height [mm] 420 540
Rear seat height [mm] 330 530
Backrest angle [°] 65 105
Backrest height [mm] 225 500
Distance footrest to seat [mm] 200 500
Distance armrest to seat [mm] 215 310
Angle footrest to seat bottom [°]
2)
0 30
Push ring diameter [mm] 470 560
Minimum turning radius [mm]
3)
440 ---
Positioning of the armrest [mm] 240 270
Horizontal axle position [mm] 62 142
1)
With wheelbase extension: rear axle position + 80mm
2)
Specified for "angle-adjustable" footrests
3)
In accordance with ISO 7176-5
31Ventus
Technical data
