Otto Bock Ventus - Page 32

Overall length [mm]
Seat depth Lower leg
length
min./max.
22" rear wheel 24" rear wheel 25" rear wheel
Front axle
position
Rear axle
position
Front axle
position
Rear axle
position
Front axle
position
Rear axle
position
200 590 670 615 695 625 705
300
500 665 745 690 770 700 780
200 610 690 635 715 645 725
320
500 685 765 710 790 720 800
200 630 710 655 735 665 745
340
500 705 785 730 810 740 820
200 650 730 675 755 685 765
360
500 725 805 750 830 760 840
200 670 750 695 775 705 785
380
500 745 825 770 850 780 860
200 690 770 715 795 725 805
400
500 765 845 790 870 800 880
200 710 790 735 815 745 825
420
500 785 865 810 890 820 900
200 730 810 755 835 765 845
440
500 805 885 830 910 840 920
200 750 830 775 855 785 865
460
500 825 905 850 930 860 940
200 770 850 795 875 805 885
480
500 845 925 870 950 880 960
200 790 870 815 895 825 905
500
500 865 945 890 970 900 980
With wheelbase extension: rear axle position +80 mm
Overall width with rear wheel with hollow rim [mm]
Seat width Overall width
280
450
300
470
320
490
340
510
360
530
380
550
400
570
420
590
440
610
460
630
480
650
500
670
Applicable to push ring attachment, narrow and a 0° camber of the rear wheels (push ring attachment, wide: +20
mm)
Increase of the overall width because of the wheel camber setting of the rear wheels [mm]
Wheel camber 22" rear wheel 24" rear wheel 25" rear wheel
3° < 60 60 > 60
32
Technical data
Ventus
