Outback Cuisine - Parts List

2
 Pre-Assembled Component
 Quantity varies according to model purchased
 Appearance, size, and construction may differ according to model purchased
Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see ‘Hardware Reference Diagram’.
CODE PART QTY
Outback®
Cuisine
Outback®
Connoisseur
HOOD
A1 Hood Handle 1
 
A2 Hood 1
 
A3 Hinge Pin 2
 
A4 Hinge Pin Clip 2
 
A5 Heat Indicator with Nuts 1
 
A6 Warming Basket 1
 
BODY
B1 Barbecue Body 1
 
B2 Burner

4 6
B3 Burner Clip

4 6
B4 Control Panel 1
 
B5 Knob

4 6
B6 Drip Tray 1
 
B7 Drip Pan 1
 
B8 Foil Liner 1
 
B9 Briquette Basket 2
 
B10 Briquettes 2
 
B11 Griddle 1
 
B12 Grill 2
 
TROLLEY
C1 Side Burner 1
 
C2 Side Burner Grill 1
 
C3 L/H Side Burner Shelf with Lid 1
 
C4 Tool Hook 1
 
C5 R/H Side Shelf 1
 
C6 Towel Rail 1
 
C7 Hose (if supplied)

C8 L/H Panel 1
 
C9 Divider 1

C10 R/H Panel 1
 
C11 Top Panel 1
 
C12 Back Panel 1
 
C13 Bottom Panel 1
 
C14 L/H Door 1
 
C15 R/H Door 1
 
C16 Door Handle 2
 
C17 Magnet Strip 2
 
C18 Caster 2
 
C19 Lockable Caster 2
 
C20 Heat Shield 1
 
C21 Mounting Bracket 1
 
C22 Ignition Assembly 1
 
C23 Support 1

ROTISSERIE
D1 Rotisserie Handle 1
 
D2 Fork 2
 
D3 Spit Rod 1
 
D4 Motor 1
 
D5 L/H Bracket 1
 
D6 R/H Bracket 1
 
HARDWARE
E1 Screw, M6x15 28
 
E2 Nut, M6 22
 
E3 Bolt, M6x90 8
 
E4 Washer 8
 
E5 Spacer 8
 
E6 Wing Nut, M6 8
 
E7 Screw, M5x10 4
 
E8 Nut, M5 4
 
