Assembly
IMPORTANT!
• Tools Required: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric
spanner set
• The assembly of this barbecue requires 2 people.
• Carefully unpack the trolley box and remove all internal packaging before commencing assembly.
• Carefully unpack the body box and remove all internal packaging before commencing assembly. All
loose items including the grills/griddle, briquette baskets and warming basket must be removed from the
body.
• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
1
2
Attach the L/H Panel (C8) to the Bottom Panel (C13) using the Screws (E1) and Nuts (E2).
Attach the R/H Panel (C10) to the Bottom Panel (C13) using the Screws (E1) and Nuts (E2).
* A sticker on the
panels indicates the
position for easy
assembly.
L/H
L/H R/H
