Before you congure your inputs, there are a few
important notes about what combinations are supported
by the Model 975:
 All HDMI inputs can be assigned to the Disc, Game,
Aux, Video and TV inputs.
 The Component 1 input, S-Video 1 input and Compos-
ite Video 1 input can be assigned only to the TV, Game
and Aux inputs.
 The Component 2 input, S-Video 2 input and Compos-
ite Video 2 input can be assigned only to the Disc and
Video inputs.
 To congure your Model 975’s inputs:
1. Use the remote control’s menu button and naviga-
tion keys to access the Input Setup menu.
2. Select the input you want to congure.
3. Now select the video input you want to use.
The available options for TV, GAME and AUX are:
HDMI 1  HDMI 2  HDMI 3  HDMI 4 
-----  CVSB1  S-Video1  YPbPr1
The available options for DISC and VIDEO are:
HDMI 1  HDMI 2  HDMI 3  HDMI 4 
-----  CVSB2  S-Video2  YPbPr2
Select NONE if you are conguring an audio-only source,
such as a satellite radio tuner or turntable.
4. Then select the audio input you want to use.
The available options are:
HDMI x  HDMI ARC  Analog  COAX 1 
COAX 2  OPT 1  OPT 2
If you selected one of the HDMI inputs in step 3, it will be displayed
as one of the choices here.
Video Input
Audio Input
Lip Sync
: HDMI 1  
: HDMI 1  
: 0ms  
HDMI1 HDMI2 HDMI3 HDMI4
----- CVSB1 S-Video1 YPbPr1
HDMIx HDMI ARC Analog
COAX1 COAX2 OPT1 OPT2
HDMI1 HDMI2 HDMI3 HDMI4
----- CVSB2 S-Video2 YPbPr2
0ms 10ms 20ms
… 300ms
Video Input
Audio Input
Lip Sync
HDMI 1
HDMI 1
0ms
:
:
:
 
 
 
DISC
Input Menu Input Options
If an HDMI video source is not selected, you cannot select
one of the HDMI inputs as your audio source. However, you
can select to receive audio from this input through an HDMI/ARC
connection from your TV. See pages 22-23 for more information.
5. Repeat the process for each input that you want to
congure in your system.
6. When you are nished, use the remote control’s
menu button and navigation keys to access the
next menu, or exit the OSD.
TV, GAME
and AUX
DISC and
VIDEO
If you select an HDMI input
from the menu above, it will be
available as a choice for your
audio input as well.
