2.Safety Terms and Symbols
2
2. Safety Terms and Symbols
Safety Terms
Terms in this manual (The following terms may appear in this manual):
Warning: Warning indicates conditions or practices that could result in injury or
loss of life.
Caution: Caution indicates the conditions or practices that could result in
damage to this product or other property.
Terms on the product. The following terms may appear on this product:
Danger: Indicates an immediate hazard or injury possibility.
Warning: Indicates a possible hazard or injury.
Caution: Indicates potential damage to the instrument or other property.
Safety Symbols
Symbols on the product. The following symbol may appear on the product:
Hazardous Voltage
Refer to Manual
Protective Earth Terminal
Chassis Ground
Test Ground

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Owon SDS1104 and is the answer not in the manual?

Owon SDS1104 Specifications

General IconGeneral
Bandwidth100 MHz
Channels4
Sample Rate1 GSa/s
Memory Depth10Mpts
Vertical Sensitivity2 mV/div to 10 V/div
Timebase Range5 ns/div to 50 s/div
Trigger TypesEdge, Pulse, Video, Slope, Alternate
Math Functions+, -, *, /, FFT
Trigger ModesAuto, Normal, Single
Display7 inch TFT LCD
Vertical Resolution8 bit
Display Resolution800 x 480
InterfaceUSB Host, USB Device, LAN
Input Impedance1MΩ
Input Voltage Range400 V (DC + AC peak)
Record Length10 Mpts
