7.Communication with Android Device via Wi-Fi (Optional)
keyboard to set the access point name.
(3) In the right menu, select Encryption, push again to set the type. Open type
needs no password. WEP or WPA type need to set the password. You can
select WPA. In the right menu, select Password, use the keyboard to set the
Wi-Fi password (8 to 32 characters).
(4) In the right menu, select IP:PORT, IP is fixed by the oscilloscope, and cannot
be edited. Click or to set the PORT.
(5) After setting, select ON in the Status menu. The icon appears on the top
right of the screen.
(6) Select Save set in the bottom menu to save current settings.
(7) In Android device, enter the Wi-Fi settings, select the oscilloscope access point
to connect, enter the set password.
(8) In Android device, launch the application.
(9) Click connect on the left.
