4.Advanced User Guidebook
Set the data width of each frame to match the signal.
It can be set to 5, 6, 7 or 8.
Set the even-odd check mode to match the polarity
used by the signal.
Set the display format of the bus.
Select "ON" to display the event table.
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB
storage device.
Select "ON" to display the ASCII table.
2. I2C Decoding
To decode I2C signal:
(1) Connect the clock line (SCLK) and the data line (SDA) of the I2C signal to
the Signal Input Channels of the oscilloscope.
(2) Adjust to the proper time base and voltage division.
(3) In trigger menu, select Bus trigger, and select bus type as I2C, set
parameters based on the characteristics of the signal, trigger the signal
correctly and obtain stable display. Refer to "I2C Trigger" on page 40.
(4) Click to call up the menu panel. Click the Decode softkey on panel to
switch to the ON state. Select bus type as I2C. set parameters based on
the characteristics of the signal. When the parameters are set correctly,
the information carried by the signal will be displayed.
Tip: If there are repetitive menu items in both trigger menu and decoding menu,
you can set anyone of them, the other will be changed synchronously.
Decoded information interpretation:
R, Read, or do not display
W, Write, or do not display
D, Data, or do not display
Note:
Use the upper knob to adjust the thresholds of bus trigger and bus
decoding.
When the ACK (ACKnowledge Character) is not met, two red error marks
