4.Advanced User Guidebook
Mode, Length, PERF Mode, and Intrpl is shown in the bottom menu.
The description of the Acqu Mode menu is shown as follows:
Use to capture maximal and minimal
samples. Finding highest and lowest
points over adjacent intervals. It is used
for the detection of the jamming burr and
the possibility of reducing the confusion.
It is used to reduce the random and
don't-care noises, with the optional
number of averages.
Set the waveform refresh rate, you can
turn on this mode when you need to
observe a single waveform
The description of the Record Length menu is shown as follows:
Choose the record length
Note: When two channels are turned on,
the max record length is 20M; and max
40M for one channel.
The description of PERF Mode menu is shown as follows:
Set the vertical resolution (A/D)
The description of the Intrpl menu is shown as follows:
Use sine(x)/x interpolation
Interpolation method is a processing method to connect the sampled points,
using some points to calculate the whole appearance of the waveform. Select
the appropriate interpolation method according to the actual signal.
Sine(x)/x interpolation: Connect the sampled points with curved lines.
Linear interpolation: Connect the sampled points with straight lines. This
