4.Advanced User Guidebook
1. Click to call up the menu panel. Click the Utility softkey on panel,
select Function in the bottom menu, select Configure in the left menu,
select About in the bottom menu. View the model and the currently
installed firmware version.
2. From a PC, visit www.owon.com and check if the website offers a newer
firmware version. Download the firmware file. The file name must be
*.update. The file name can be up to 15 characters long (including the
suffix). Copy the firmware file onto your USB memory device.
3. Insert the USB memory device into the side panel USB port on your
instrument.
4. Click to call up the menu panel. Click the Utility softkey on panel,
select Function in the bottom menu, select Update in the left menu.
5. Select Open in the bottom menu, the instrument lists a directory of the
folders on the USB memory device. Turn the upper knob to select a folder,
select Open in the bottom menu to enter the folder. Navigate to the folder
where the firmware file is, and select the file with the .update suffix.
6. In the bottom menu, select Open, the messages below will be shown.
7. In the bottom menu, select Start again, the interfaces below will be
displayed in sequence. The update process will take up to three minutes.
After completion, the instrument will be shut down automatically.
8. Long press the
button to power on the instrument.
