4.Advanced User Guidebook
When the horizontal time base is ≤50ms, the horizontal time base can be
expanded for 4 divisions downwards.
Single
Push this button you can set the trigger mode as single directly, so when
trigger occurs, acquire one waveform then stop.
Autoset
It's a very useful and quick way to apply a set of pre-set functions to the
incoming signal, and display the best possible viewing waveform of the signal.
The details of functions applied to the signal when using Autoset are shown
as the following table:
Adjust to the proper division.
Adjust to the proper position.
Adjust to the proper division
The previous source before autoseting.
When the previous source has no input signal, the
source will be set to the minimum channel which
has input signal.
When all the channels have no input signal, the
source will be set to CH1.
If greater than 10M, it will be set to 10M
