Owon TAO3000 Series User Manual

9.Technical Specifications
121
Performance Characteristics
Instruction
Single CH
500 MSa/s
14 bits
mode
Four CH
100 MSa/s
Dual CH
100 MSa/s
Single CH
100 MSa/s
Input
Input coupling
DC, AC, Ground
Input impedance
1 MΩ±2%, in parallel with 15 pF±5 pF
Input coupling
0.001X - 1000X, step by 1 – 2 - 5
Max input voltage
400 V (DC + AC Peak)
Bandwidth limit
20 MHz, full bandwidth
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel(typical)
150ps
Horizontal
System
Sampling rate range
TAO3074
TAO3104
Four CH
0.05 Sa/s -
250 MSa/s
Dual CH*
0.05 Sa/s -
500 MSa/s
Single CH
0.05 Sa/s -
1 GSa/s
TAO3074A
TAO3104A
8 bits
mode
Four CH
0.05 Sa/s -
250 MSa/s
Dual CH*
0.05 Sa/s -
500 MSa/s
Single CH
0.05 Sa/s -
1 GSa/s
12 bits
mode
Four CH
0.05 Sa/s -
125 MSa/s
Dual CH*
0.05 Sa/s -
250 MSa/s
Single CH
0.05 Sa/s -
500 MSa/s
14 bits
mode
Four CH
0.05 Sa/s -
100 MSa/s
Dual CH
0.05 Sa/s -
100 MSa/s
Single CH
0.05 Sa/s -
100 MSa/s
Interpolation
(Sinx)/x, x
Max Record length
When four channels are turned on, the max
record length is 10M; and max 20M for two
channels; max 40M for one channel.
Scanning speed (S/div)
2ns/div - 1000s/div, step by 1 – 2 - 5
