Owon TAO3000 Series User Manual

4.Advanced User Guidebook
80
7. In the bottom cursor menu, you can select Window as Main to make
the cursors shown in the main window.
Use Mathematical Manipulation Function
The Mathematical Manipulation function is used to show the results of the
addition, multiplication, division and subtraction operations between two
channels, advanced math feature including Intg, Diff, Sqrt, user defined
function, and digital filter. Click to call up the menu panel. Click the Math
softkey on panel to switch to the ON state and display the math menu on the
bottom.
The Waveform Calculation menu:
Function Menu
Setting
Description
Waveform
Math
Factor1
CH1
CH2
CH3
CH4
Select the signal source of the factor1
Sign
+ - * /
Select the sign of mathematical
manipulation
Factor2
CH1
CH2
CH3
CH4
Select the signal source of the factor2
Vertical
(div)
Click or to adjust the vertical position of the
Math waveform
Vertical
(V/div)
Click or to adjust the vertical division of the
Math waveform
User
Function
Edit fun
Intg, Diff, Sqrt, and user defined function
Vertical
(div)
Click or to adjust the vertical position of the
Math waveform
Vertical
(V/div)
Click or to adjust the vertical division of the
Math waveform
DIR
channel
CH1
CH2
Select channel
type
low-pass
Only the signals whose frequencies are
lower than the current cut-off frequency
can pass the filter.
high-pass
Only the signals whose frequencies are
greater than the current cutoff frequency
can pass the filter.
