Single, set the trigger mode to Edge, select the signal source.
2. Click , click the Display softkey on panel.
3. Select Counter as ON or OFF in the bottom menu.
Save and Recall a Waveform
Click to call up the menu panel. Click the Save softkey on panel, you can
save the waveforms, configures, screen images, record or clone the waveform.
The description of the Save Function Menu is shown as the following table:
Function Menu
Setting
Description
Type
Wave
Configure
Record
Clone
Choose the saving type.
About the Record type, see
"Record/Playback Waveforms" on P63.
About the Clone type, see “Clone and
Recall a waveform” on P67.
When the type is Wave, the menu shows as following:
Type
Wave
Format
(Right menu)
For internal storage, only BIN can be
selected. For external storage, the
format can be BIN, TXT or CSV.
Source
CH1
CH2
CH3
CH4
Math
(or MathFFT)
Check the waveform to be saved. (If
certain channel is off, the
corresponding menu item will be
disabled.)
Object
& Show
Object
Wave0 to
Wave99
Choose the address which the
waveform is saved to or recall from.
Show
ON
OFF
Recall or close the waveform stored in
the current object address. When the
show is ON, if the current object
address has been used, the stored
waveform will be shown, the address
number and relevant information will be
displayed at the top left of the screen; if
the address is empty, it will prompt
"None is saved".
Close All
Close all the waveforms stored in the
object address.
