4.Advanced User Guidebook
Save the waveform of the source to the
selected address. Whatever the Type
of save menu is set, you can save the
waveform by just pressing the Copy
panel button in any user interface.
Select Type in the bottom menu, in the
right Format menu, you can select the
storage format.
Save to internal storage or USB
storage. When External is selected,
save the waveform according to the
current record length (see "Record
Length menu" on P49); the file name is
editable. The BIN waveform file could
be open by OWON waveform analysis
software (on the supplied CD).
When the type is Configure, the menu shows as following:
Save the current oscilloscope configure
to the internal storage
Recall the configure from the selected
address
When the type is Image, the menu shows as following:
Save the current display screen. The
file can be only stored in a USB
storage, so a USB storage must be
connected first. The file name is
editable. The file is stored in BMP
format.
Save and Recall the Waveform
The oscilloscope can store 100 waveforms, which can be displayed with the
current waveform at the same time. The stored waveform called out cannot be
adjusted.
In order to save the waveform of CH1, CH2 and Math into the address 1, the
operation steps should be followed:
1. Turn on CH1, CH2 and Math channels.
2. Click to call up the menu panel. Click the Save softkey on panel.
3. Saving: Select Type in the bottom menu, select Wave in the left menu.
