4.Advanced User Guidebook
select Function in the bottom menu, select Adjust in the left menu.
3. Select ProbeCh. in the bottom menu, tips about probe checking shows on
the screen.
4. Select ProbeCh. again to begin probe checking and the checking result
will occur after 3s; push any other key to quit.
● Output
Click to call up the menu panel. Click the Utility softkey on panel, select
Function in the bottom menu, select Output in the left menu.
Output menu item in the bottom menu sets the output type of Trig Out (P/F)
connector on Side Panel. In the bottom menu, select Output. The description
of Output menu is shown as the follows:
Device and Print Set menu items set the print output, refer to "Print the
Screen Image" on page 94.
● LAN Set
Using the LAN port or Wi-Fi, the oscilloscope can be connected with a
computer. The oscilloscope also supports communications with Android based
smart device via Wi-Fi. Refer to "Communication with PC" on page 96 and "
Communication with Android Device via Wi-Fi (Optional)" on page 104 for the
operation steps.
● Update
Use the side panel USB port to update your instrument firmware using a USB
memory device. Refer to "Update your Instrument Firmware" on page 70.
Set the Display System
Click to call up the menu panel. Click the Display softkey on panel, the
Display menu is shown as follows:
Output trig signal synchronously
Output High Level when Pass, and Low Level when
Fail
To Next Page
