4.Advanced User Guidebook
Select "ON" to display the event table.
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB
storage device.
Select "ON" to display the ASCII table.
Implement Sampling Setup
Click to call up the menu panel. Click the Acquire softkey on panel, Acqu
Mode, Length, PERF Mode, and Intrpl is shown in the bottom menu.
The description of the Acqu Mode menu is shown as follows:
Use to capture maximal and minimal
samples. Finding highest and lowest
points over adjacent intervals. It is used
for the detection of the jamming burr and
the possibility of reducing the confusion.
It is used to reduce the random and
don't-care noises, with the optional
number of averages.
Set the waveform refresh rate, you can
turn on this mode when you need to
observe a single waveform
The description of the Record Length menu is shown as follows:
Choose the record length
Note: When four channels are turned on,
the max record length is 10M; and max
20M for two channels; max 40M for one
channel.
The description of PERF Mode menu is shown as follows:
Set the vertical resolution (A/D)
To Next Page
