Owon TAO3000 Series User Manual

4.Advanced User Guidebook
77
Type
Voltage
Time
Time&Voltage
AutoCursr
Display the voltage measurement cursor and
menu.
Display the time measurement cursor and
menu.
Display the time and voltage measurement
cursor and menu.
The horizontal cursors are set as the
intersections of the vertical cursors and the
waveform
Line
Type
(Time&Volt
age type)
Time
Voltage
Makes the vertical cursors active.
Makes the horizontal cursors active.
Window
(Wave
zoom
mode)
Main
Extension
Measure in the main window.
Measure in the extension window.
Source
CH1 to CH4
Display the channel to which the cursor
measurement will be applied.
Perform the following operation steps for the time and voltage cursor
measurement of the channel CH1:
1. Click to call up the menu panel. Click the Cursor softkey on panel
to switch to the ON state and display the cursor menu.
2. Select Source in the bottom menu, select CH1 in the right menu.
3. Select the first menu item in the bottom menu, the Type menu will
display at the right of the screen. In the right menu, select
Time&Voltage for Type, two blue dotted lines displayed along the
horizontal direction of the screen, two blue dotted lines displayed along
the vertical direction of the screen. Cursor measure window at the left
bottom of the screen shows the cursor readout.
4. In the bottom menu, select Line Type as Time to make the vertical
cursors active. Click line a to select it, swipe left/right to move it. Click
line b to select it, swipe left/right to move it.
5. In the bottom menu, select Line Type as Voltage to make the
horizontal cursors active. Click line a to select it, swipe up/down to
move it. Click line b to select it, swipe up/down to move it.
6. Push the Horizontal HOR button to enter wave zoom mode. In the
bottom cursor menu, select Window as Main or Extension to make
the cursors shown in the main window or zoom window.
