Page #95 background image
PEC017
5/3/2018 Page 95 of 105
N102
Page 45
Min
Default
Max
Signal Source for Remote Main
Switch
0
0
1
* 0 = Hardwired 12V
1 = CAN Signal
N103
Page 22
Min
Default
Max
Engine Speed Increase w/ Set/Accel
10
250
1000
N104
Page 22
Min
Default
Max
Engine Speed Decrease w/
Res/Decel
10
250
1000
N105
Page 22
Min
Default
Max
Engine Speed Ramp-down w/
Res/Decel
10
100
1900
N106
Page 55
Min
Default
Max
PTO Mode Minimum Engine Speed
N052
650
2000
* Must be greater than or equal to Engine Idle Speed (N052)
* May not be greater than 800 RPM if Require Parking Brake for PTO Mode
(N079) and Neutral Required for PTO Mode (N089) are disabled
* May not be greater than 950 RPM if Require Parking Brake for PTO Mode
(N079) and Neutral Required for PTO Mode (N089) are disabled, and Disable PTO
Mode w/ Brake Depressed(N106) is enabled.
N107
Page 22
Min
Default
Max
Engine Speed Ramp-Up w/
Set/Accel
10
100
1900
N109
Page 56
Min
Default
Max
Enable PTO Mode Engine Ramp
Rate Limiter
OFF (0)
OFF (0)
ON (1)
