PACSystems RX3i - Page 51

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 47
%AI Word
Offset
Value
Comments
22
GRID 1– Total Power Factor
23
GRID 1– Line Frequency
24
GRID 1– Total 15-minute Active Power
Demand
25
GRID 1– Total 15-minute Reactive Power
Demand
26
GRID 1– Total Active Energy - LSW
27
GRID 1– Total Active Energy - MSW
28
GRID 1– Total Reactive Energy - LSW
29
GRID 1– Total Reactive Energy - MSW
30
GRID 2– Phase A Voltage – RMS value (phase-
to-neutral)
WYE configuration only In Delta
configuration always 0
31
GRID 2– Phase Ap Voltage – RMS value
(phase-to-phase)
WYE and Delta configurations
32
GRID 2– Phase A Voltage – DC component
33
GRID 2– Phase A Current – RMS value
34
GRID 2– Phase A Active Power
35
GRID 2– Phase A Reactive Power
36
GRID 2– Phase Bn Voltage – RMS value (phase-
to-neutral)
WYE configuration only In Delta
configuration always 0.
37
GRID 2– Phase Bp Voltage – RMS value
(phase-to-phase)
WYE and Delta C-common
configurations Delta B-common
always 0
38
GRID 2– Phase B Voltage – DC component
39
GRID 2– Phase B Current – RMS value
WYE and Delta C-common
configurations Delta B-common
always 0
40
GRID 2– Phase B Active Power
41
GRID 2– Phase B Reactive Power
42
GRID 2– Phase Cn Voltage – RMS value (phase-
to-neutral)
WYE configuration, only In Delta
configuration always 0
43
GRID 2– Phase Cp Voltage – RMS value (phase-
to-phase)
WYE and Delta B-common
configurations Delta C-common
always 0
44
GRID 2– Phase C Voltage – DC component
