PACSystems RX3i - Mode Control Bits and Parameter Management

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 49
%AI Word
Offset
Value
10
GRID 1-Section B Current – RMS value
11
GRID 1-Section B Active Power
12
GRID 1-Section B Reactive Power
13 – 18
N/A
19
GRID 1-Neutral Current – RMS value
20
GRID 1 – Total Active Power
21
GRID 1 – Total Reactive Power
22
GRID 1-Total Power Factor
23
GRID 1-Line Frequency
24
GRID 1-Total 15-minute Active Power Demand
25
GRID 1-Total 15-minute Reactive Power Demand
26
GRID 1-Total Active Energy – LSW
27
GRID 1-Total Active Energy – MSW
28
GRID 1-Total Reactive Energy – LSW
29
GRID 1-Total Reactive Energy – MSW
30
GRID 2-Section A Voltage – RMS value
31
N/A
32
GRID 2-Section A Voltage – DC component
33
GRID 2-Section A Current – RMS value
34
GRID 2-Section A Active Power
35
GRID 2-Section A Reactive Power
36
GRID 2-Section B Voltage – RMS value
37
N/A
38
GRID 2-Section B Voltage – DC component
39
GRID 2-Section B Current – RMS value
40
GRID 2-Section B Active Power
41
GRID 2-Section B Reactive Power
42 – 47
N/A
48
GRID 2-Neutral Current – RMS value
49
GRID 2 – Total Active Power
50
GRID 2 – Total Reactive Power
51
GRID 2-Total Power Factor
52
GRID 2-Line Frequency
53
GRID 2-Total 15-minute Active Power Demand
54
GRID 2-Total 15-minute Reactive Power Demand
55
GRID 2-Total Active Energy - LSW
56
GRID 2-Total Active Energy - MSW
