PACSystems RX3i - Page 59

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 55
Index
(%AQ
Word 1)
Parameter Value
(%AQ Word 2)
Default value
Value Limits
13
GRID 1 Nominal Voltage
1200 [0.1 V]
450 to 1500 or 1200 to 7500
14
GRID 1 Nominal Current
5000 [0.001 A]
-7500 to 7500
5
15
GRID 1 Nominal Frequency
6000 [0.01 Hz]
5000 or 6000
16
GRID 2 MODULE OFFSET
0
Calibrated value, -1000 to +1000
17
GRID 2 MODULE GAIN
0x4000
Calibrated value, 0h to FFFFh
18
GRID 2 VA2 GAIN LOW
0x4000
Calibrated value, 0h to FFFFh
19
GRID 2 VA2 GAIN HIGH
0x4000
Calibrated value, 0h to FFFFh
20
GRID 2 IA2 GAIN
0x4000
Calibrated value, 0h to FFFFh
21
GRID 2 VB2 GAIN LOW
0x4000
Calibrated value, 0h to FFFFh
22
GRID 2 VB2 GAIN HIGH
0x4000
Calibrated value, 0h to FFFFh
22
GRID 2 IB2 GAIN
0x4000
Calibrated value, 0h to FFFFh
23
GRID 2 VC2 GAIN LOW
0x4000
Calibrated value, 0h to FFFFh
26
GRID 2 VC2 GAIN HIGH
0x4000
Calibrated value, 0h to FFFFh
26
GRID 2 IC2 GAIN
0x4000
Calibrated value, 0h to FFFFh
27
GRID 2 IN2 GAIN
0x4000
Calibrated value, 0h to FFFFh
28
GRID 2 Nominal Voltage
1200 [0.1 V]
450 to 1500 or 1200 to 7500
29
GRID 2 Nominal Current
5000 [0.001 A]
-7500 to 7500
6
30
GRID 2 Nominal Frequency
6000 [0.01 Hz]
5000 or 6000
31
PHASE_SHIFT_ THR (ANSI 25/1a)
100 [0.1 el°]
1 to 450
32
Breaker Delay (ANSI 25/b1)
0 (msec)
1 to 1000
33
DELTA_VOLT_THR (ANSI 25/2)
10 [%]
1 to 1000
34
DELTA_FREQ_THR (ANSI 25/3)
10 [0.01 Hz]
1 to 500
35
UNDER_VOLT_THR (ANSI 27a)
90 [%]
0 to 99
36
UNDER_VOLT_DELAY (ANSI 27b)
100 [0.1 sec]
1 to 32767
37
PWR_REV_THR (ANSI 32a)
-10 [%]
-100 to +99
38
PWR_REV_DELAY (ANSI 32b)
100 [0.1 sec]
1 to 32767
39
OVER_CURR_THR (ANSI 50a)
110 [%]
101 to 250
40
OVER_CURR_DELAY (ANSI 50b)
100 [0.1 sec]
1 to 32767
41
OVER_VOLT_THR (ANSI 59a)
115 [%]
101 to 250
42
OVER_VOLT_DELAY (ANSI 59b)
100 [0.1 sec]
1 to 32767
43
VI_IMBALANCE_THR (ANSI 60a)
10 [%]
1 to 100
44
VI_IMBALANCE_DELAY (ANSI
60b)
100 [0.1 sec]
1 to 32767
45
UNDER_FRQ_THR (ANSI 81Ua)
50 [0.01 Hz]
1 to 1000
5
A negative value of the Grid 1 or Grid 2 nominal current (Parameter # 14 or #29) means that the Grid’s total active power under normal
conditions is expected to have a negative sign. The user is responsible for the correct PT/CT connections to get the negative sign for the
active power of each phase
6
A negative value of the Grid 1 or Grid 2 nominal current (Parameter # 14 or #29) means that the Grid’s total active power under normal
conditions is expected to have a negative sign. The user is responsible for the correct PT/CT connections to get the negative sign for the
active power of each phase.
