S3L-24P Layer 3 Lite Managed Switch Hardware Installation Guide
2
Introduction
Switch description
The S3L-24P Layer 3 Lite Managed Switch is targeted for the deployment in Small-to-Medium Businesses
(SMB) providing 10 Gbps Ethernet wire-speed connections that can be used to uplink servers or to
interconnect switches within the LAN. For medium-to-large scale enterprise deployment, these switches
provide an excellent means to interconnect edge switches and core switches.
This switch features twenty-four 10/100/1000Mbps RJ45 copper Power over Ethernet (PoE) ports and four
1/10Gbps SFP+ module ports.
This switch supports the latest IEEE 802.3az Energy-Efficient Ethernet (EEE) standard to save power while
links are online or to notify selective ports automatically to enter into the standby mode when no traffic is
being transmitted or received.
Package contents
After purchasing this switch, the following items will be included in the package:
• One S3L-24P Switch.
• One Quick Start Guide (QSG).
• One AC power cord.
• One RS-232-to-RJ45 console cable.
• One pair of rack-mount brackets.
• Eight Phillips-head rack-mount bracket screws.
If any of the above mention items was not found inside the package contents of this switch or are
damaged in any way, contact the your reseller immediately.
