145
Slide-in Unit:
Box-type Unit:
47 Oil drain plug
48 Hydraulic oil reservoir
49 Suction filter in the oil reservoir
50 Breather filter
51 Valve block
51
50
48
49
47
51
50
48
49
47
Betriebsanleitung_Hubladebuehnen_EN.book Seite 145 Donnerstag, 15. August 2019 4:04 16
