36
Lifting the Platform
Before the platform is lifted it tilts to the horizontal position.
While the platform is lifted it remains in horizontal position.
Lift the platform depending on the model by means of the
lateral operating element, the foot control, or the hand cable
control, as described in chapter “Operating Elements” from
p. 42.
Closing/Folding In/Retracting the Platform
Close, fold in or retract the tail lift depending on the model
by means of the lateral operating element or hand cable
control, as described in chapter “Operating Elements” from
p. 42.
Close the platform interlock (if present).
Loading or Unloading the Platform
CAUTION!
Damage to the tail lift by incorrect loading!
The tail lift can be damaged if the platform load is too high or
unbalanced.
When loading the platform, do not exceed the maximum
load weight specified in the chapter “Technical Data” from
p. 168. Take the weight of the operator standing on the
platform into account. The load diagram is also shown at
the lateral operating element.
Center the load on the platform. The payload center of
gravity should be as close to the vehicle as possible. If
you load the platform on one side only, the payload
weight may be max. 50% of the permitted payload.
Rolling containers without brakes may only be loaded if
the tail lift is equipped with a roll-off protection (roll stops
or grooves). Rolling containers without brakes must al-
ways be secured by this roll-off protection.
CAUTION!
Risk of injury!
Persons can fall off the platform and suffer from injuries.
When loading the platform, leave enough free space for
the operator (minimum 50 x 60 cm).
