Model Overviews
Standard Tail Lifts
A
2 Supporting strap on body
(not in scope of delivery)
3 Lateral operating panel
4 Hydraulic unit
5 Underrun bumper
6 Lift arms switch b13,
tilt sensor b15
7 Lift arms switch b16,
tilt sensor b15
10 Foot control
11 Roll stop (roll-off
protection, optional)
12 Payload center of gravity
13 Warning lights (optional)
14 Platform
17 Torsion frame
18 Lift cylinder
19 Tilt cylinder
21 Support tube
22 Hand cable control
2
3
3
4
5
10
11
14
12
13
17
18
19
21
22
6
7
