Palfinger MBB C 1000 S - Standard Tail Lifts

18
Standard Tail Lifts
C
2 Supporting strap on body
(not in scope of delivery)
3 Lateral operating panel
4 Hydraulic unit
6 Lift arms switch b13
10 Foot control
11 Roll stop (roll-off protection,
optional)
12 Payload center of gravity
13 Warning lights
(optional)
14 Platform
17 Torsion frame
18 Lift cylinder
19 Tilt cylinder (covered by
platform)
21 Support tube
2
3
3
6
10
111214
13 13
17
18
19
21
4
