178
Tail Lift with Hydraulic Stabilizer Feet
MBB C 750 L – C 1000 L
A
TILT CYLINDER LIFT CYLINDER
STABLIZER FEET CYLINDERS
Pressure switch S8.1 adjusted to 20 bars
Betriebsanleitung_Hubladebuehnen_EN.book Seite 178 Donnerstag, 15. August 2019 4:04 16
